Processor
|
Intel Celeron J1900 2.42Ghz
|
|
Chipset Platform
|
Intel Bay Trail
|
|
Panel Size
|
10.1 Inch
|
|
Storage
|
1 x mSATA for SSD, 1 x SATA2.0
|
|
Memory
|
1 x DDR3 1600MHZ/1333MHZ RAM slot up to 8GB
|
|
Ethernet
|
1x RJ45
|
|
Cooling System
|
Fanless design
|
|
DC input
|
Support 12V input
|
|
Graphic
|
Integreted Graphic chips
|
|
Display Interface
|
1 x HDMI, 1 x VGA
|
|
LCD Interface
|
1 x LVDS
|
|
Display Resolution
|
LCD - 1280 x 800, HDMI - 1920 x 1080
|
|
Panel Type
|
16:10
|
|
Screen Size
|
10.1Inches
|
|
Luminance
|
350
|
|
Contrast Ratio
|
800：1
|
|
Display Color
|
RGB-stripe
|
|
Backlight
|
TFT-LCD
|
|
Touch Panel
|
Multi Touch Capacitive Panel
|
|
Serial Port
|
1 x RS-232, 1 x RS-485
|
|
USB
|
2 x USB2.0, 2 x USB3.0
|
|
Digital I/O
|
No
|
|
Audio
|
1 x Line-in, 1 x Line-out
|
|
OS support
|
Windows 10, Windows 7, Windows 8, Linux
|
|
Wake On LAN
|
No
|
|
Watchdog Timer
|
No
|
|
Operating Temperature
|
0 ºC ~ 60 ºC
|
|
Front panel material
|
Aluminum
|
|
Back chassis material
|
Aluminum
|
|
Mounting Option
|
75 x 75mm, 216 x 86mm VESA Mount (Panel mount optional)
|
|
Dimension
|
263 x 176 x 32mm
|
|
Storage Temperature
|
-10 ºC ~ 70 ºC
|
|
Gross Weight
|
2.5kg
|
